Steinway Lyngdorf

The 2-channel A1 and 4-channel A2 fully digital amplifiers are unique in their construction as well as their performance, and are the premier choice for both stereo and surround sound setups.

They utilize true digital amplification, thus ensuring that signal processing is handled 100% in the digital domain without any sound-deteriorating analog conversions.


Steinway Lyngdorf commits to a new level of support for the Digital Cinema Initiative (DCI) with a collection of speakers designed for the ultimate Hollywood cinema and large format screening rooms. The X speakers are made specifically for both private and commercial projects that demand the highest possible performance. Designed for dedicated in-wall use, the X speakers are based on the already high-performing In-Wall Series but offer a more powerful level of performance.

The Model D is a full range floor-standing dipole speaker which emits sound from both front and back. Unrestricted by the vibrations of conventional cabinets, it interacts with the room like a Steinway & Sons grand piano does, resulting in extremely open and life-like musicality, with no resonance and no coloration.

This full-range loudspeaker is designed to provide the legendary Steinway & Sons performance in a small package without the need for a separate woofer. The Steinway & Sons Model O functions impeccably as a surround speaker or a simple stereo setup, and its small footprint makes it a perfect alternative to wall mounted speakers.

This full range loudspeaker is designed for creating the holographic stereo reproduction of the Steinway & Sons Model D speakers through use of the dipole speaker concept – all in a smaller package.

The Steinway & Sons Model B not only looks powerful with its impressive line-up of drivers, but together with the digital crossover and true quad-amplification of the 4 x 400-watt digital amplifier, Steinway & Sons Model A2, the resulting sound reproduction is nothing short of stunning.

Steinway & Sons P300 2.1 surround sound processor from Steinway Lyngdorf is built for the demanding connoisseur, who requires the ultimate performance in immersive formats as well as stereo. With the new state-of-the-art HDMI and decoder boards, the P300 2.1 pass-through 4K-60Hz video with full decoding of 16 native channels and support of up to 256 speakers – all with RoomPerfect™ room correction and intelligent bass management.

Audio: 5 x HDMI™ (≤192kHz/24bit), 1 x AES/EBU S/P-DIF input (192kHz/24bit), 3 x S/P-DIF coaxial inputs (192kHz/24bit), 4 x S/P-DIF optical inputs (≤96Hz/24bit), 1 x USB audio input (≤192kHz/32bit), 1 x microphone input (XLR) for RoomPerfect™, 1 x balanced stereo analog input (XLR), 4 x single ended stereo analog inputs (RCA), 1 x multichannel single ended analog input (RCA)
Video: 5 x HDMITM (2.1 – HDCP 2.3), accepts 8k30 RGB/YCbCr 4:4:4 10-bit video, 8k60 YCbCr 4:2:0 10-bit high definition video, and 4k120 4:4:4 10-bit high frame rate video, Variable refresh rate (VRR), fast vactive (FVA), and auto low latency mode ALLM) support. accepts HDR, Dolby Vision™ and HLG

Audio: 5 x Steinway Lyngdorf Digital Links (CAT 5e based), 1 x single ended stereo analog output for secondary audio output (Zone 2), 1 x SPDIF coax digital stereo output for secondary audio output (Zone 2 / Fix: 96kHz/24bit)
Video: 2 x HDMI™ (2.1b, eARC compatible)

Frequency response: ±0,5dB from 20 to 20,000 Hz

1 x DB9 RS232 connector, 2 x IR sensor inputs, 1 x IR output (loop from one of the sensor inputs), 1 x trigger input, 4 x trigger outputs, 1 x RJ45 ethernet LAN connector, 2 x USB connectors (backup, updates + FAT32 media storage), 1 x SD card slot (backup – storage for system software and settings)

Steinway Lyngdorf commits to a new level of support for the Digital Cinema Initiative (DCI) with a collection of speakers designed for the ultimate Hollywood cinema and large format screening rooms.

The X speakers are made specifically for both private and commercial projects that demand the highest possible performance. Designed for dedicated in-wall use, the X speakers are based on the already high-performing In-Wall Series but offer a more powerful level of performance.

The Model M series is anything you want it to be. For style-conscious audio enthusiasts who prefer a discreet, customizable installation, the Model M delivers.

The system’s slim and stylish architectural speakers can be mounted on wall, semi on wall, or in wall. Whether a large home theater or an intimate living room, your environment reflects your design style. The Model M just makes it sound better.

The In-Wall series speakers are specifically designed to be placed behind acoustically transparent screens, fabric panels, and metal mesh grills. With invisible presence, the In-Wall series offers exceptional performance, versatility, and unbeatable appeal.

This series can be mixed-and-matched with any other item in our product range while maintaining the outstanding performance of each individual component.

Gold Note

Goldmund

The Telos 2800 Mono Power Amplifier combines outstanding performance with aesthetic appeal, reminiscent of a finely crafted jewelry box. It comes in Goldmund’s classic silver-grey finish, lending a sophisticated flair to any audio setup. To cater to individual tastes, customers have the choice to customize the top left front ring of their Telos 2800 in either gold* or silver grey, ensuring it complements any decor seamlessly.

< 0.05 % THD+N, < 0.05 % from 20 Hz to 20 kHz at 30 Vrms output

Output Noise Floor Analog input terminated with RCA Shorting Caps

35 dB, +/- 9 dB (adjustable in 3 dB increments)

Analogue input: 1 Vrms Digital input: -6 dBFS

22 kHz measurement bandwidth (flat), true RMS unloaded: 117 dB

1 x Main fuse (4 A slow-blow for 230 V) ; (8 A slow-blow for 115 V)

1 x Green-yellow AC earth binding post (with bridge connection)

1 x Ground lift switch 2 x output binding posts (red & black)

1 x output Goldmund speaker 4B type connector

1 x Analogue RCA input (unbalanced connector)

1 x Analogue XLR input (balanced connector)

1 x Digital input and output RCA connectors

IEC 60065: 1/8 Output Power at 8 Ω: 365 W

44 W x 32 H x 46 D (cm) 17.3 W x 12.6 H x 18.1 D (inch), 59 kg

Elevating the auditory experience to new heights, we proudly unveil the Mimesis Signature, a convergence of analogue finesse and digital prowess. This symphony of audio excellence introduces a paradigm shift in preamplification technology.

2 x Digital S/PDIF, 1 x Toslink Optical, 1 x USB AUDIO (up to 384 kHz PCM up to DSD512)

ON/OFF power switch, key Voltage input selector, RS232 Command connector

Frequency response (These values for any level to maximum output level)

+/- 0.1 dB, 10 Hz – 20 kHz, +/- 1.5 dB, 10 Hz – 100 kHz, +/- 3 dB, 10 Hz – 200 kHz

Distortion with 1 V RMS output level, 80 KHz measurement bandwidth, 600 Ohms termination impedance

THD unbalanced in to unbalanced out < 0.005% (-90 dB) flat with frequency

IMD unbalanced in to unbalanced out < 0.002% (-80 dB)

117 or 234 V (switchable) Fuse 2.5A for 110V Fuse 1A for 220V Input voltage range: +/- 10 %

Lyngdorf

The MXA-8400 is the most powerful product from Lyngdorf Audio ever, delivering 8 x 400 watts of ultra-linear and stable power. It incorporates Purifi EIGENTAKT technology with the innovative EIGENTAKT ErrorCorrection (EEC), Lyngdorf Audio’s highly efficient and advanced power supply PowerPerfect, ultra-low-noise and precise analog input stages, and a 4-layer main PCB optimized for the best signal purity and grounding. With this range of features, the MXA-8400 sets new amplifier benchmarks in audio quality, measured performance, and reliability.

8 x 400 W @4Ω (2-CHANNEL mode), 8 x 200 W @8Ω (2-CHANNEL mode), 4 x 800 W @8Ω (BRIDGE mode)


8 x 340 W @4Ω (2-CHANNEL mode), 8 x 200 W @8Ω (2-CHANNEL mode)


15 minutes (at no input signal, in LOW POWER mode)

0.001% @200 W, 8Ω / 340 W, 4Ω, 20Hz-20kHz, 0.0006% @10 W, 4Ω, 20Hz-20kHz, LOW Sensitivity mode, 0.0007% @10 W, 4Ω, 20Hz-20kHz, HIGH Sensitivity mode


 58V peak (2-CHANNEL mode), 116V peak (BRIDGE mode))
Gain: HIGH Sensitivity mode: 26.1 dB (2-CHANNEL mode), 31.7 dB (BRIDGE mode)

16.6 dB (2-CHANNEL mode) 22.2 dB (BRIDGE mode)

128dB (A-weighted ref. rated power, LOW Sensitivity mode)

HIGH Sensitivity mode2V, LOW Sensitivity mode 6V


The Model M series is anything you want it to be. For style-conscious audio enthusiasts who prefer a discreet, customizable installation, the Model M delivers.

The system’s slim and stylish architectural speakers can be mounted on or in walls and ceilings, partially or completely concealed, for a discreet installation of powerful speakers offering as high or low a profile as you desire. Whether a large home theater or an intimate living room, your environment reflects your design style. The Model M just makes it sound better.

The LS series is the number one choice for larger rooms and spaces with rows of elevated seats. The series features an innovative line source approach incorporating floor-to-ceiling stackable speakers and boundary woofers. This allows sound to propagate over long distances, thus ensuring tonal consistency by reducing reflections from ceiling and floor, especially in large rooms. Line source technology means that every seat in the listening space has close to the same volume level and offers the same sound experience, from the front to the rear of the room.

1 x Steinway Lyngdorf Digital Link (CAT 5e based), 1 x RJ12 RS232 connector

1 x Steinway Lyngdorf Digital Link (CAT 5e based), 4 x Speakon® speaker output
